KPP1500H12D3E4 IGBT Module Power Control 48 Pins Solution For Business
Product Details
| Contact Resistance: | 30mΩ | Voltage Rating: | 100V |
|---|---|---|---|
| Pin Count: | 48 Pins | Pin Pitch: | 0.8mm |
| Service Life: | 25,000times | Current Rating: | 1A |
| Insertion Life: | 10,000 Cycles | Contact Plating: | Gold |
| Application: | BGA Testing | Part Number: | BGA96(11.6*7.95)-0.8 Socket |
| Socket Pitch: | 0.5mm | Structure: | Clamshell |
| Material: | Ceramic | Number Of Pins: | 100 |
| Operating Temperature: | -40°C To 150°C | Product: | IGBT Module |
| Feature: | High Current | ||
| Highlight |
KPP1500H12D3E4 IGBT Module,IGBT Module Power Control,48 pins igbt power module |
||
Product Description
KPP1500H12D3E4 IGBT Module The Ultimate Power Control Solution for Your Business
Specification Parameters
| TYPE | VCES Volts |
VGES Volts |
IC Amps |
VCE(SAT) Volts |
(EON+EOFF) mJ |
TJ | Ptot | Circuit | Package | Technology |
| Watts | ||||||||||
| KPP600H12D1E4 | 1200 | ± 20 | 600A | 1.65V | 107.0mJ | 175℃ | 3100W | 2 Pack | PP 2 | Trench FS |
| KPP900H12D1E4 | 1200 | ± 20 | 900A | 1.65V | 140.0mJ | 175℃ | 5100W | 2 Pack | ||
| KPP650H17D1E4 | 1700V | ± 20 | 650A | 2.00V | 345.0mJ | 175℃ | 4150W | 2 Pack | ||
| KPP1400H12D2E4 | 1200 | ± 20 | 1400A | 1.70V | 280.0mJ | 175℃ | 7650W | 2 Pack | PP 3 | |
| KPP1000H17D2E4 | 1700 | ± 20 | 1000A | 2.00V | 465.0mJ | 175℃ | 6250W | 2 Pack | ||
| KPP1400H17D2E4 | 1700 | ± 20 | 1400A | 1.75V | 780.0mJ | 175℃ | 9550W | 2 Pack | ||
| KPP1500H12D3E4 | 1200 | ± 20 | 400A | 1.90V | 275.0mJ | 175℃ | 4800W | 2 Pack | PP 3+ |
Product Highlights
KPP1500H12D3E4 IGBT Module The Ultimate Power Control Solution for Your Business KPP1500H12D3E4 Cu Baseplate Al2O3Substrates High Thermal Cycling Capability 10μs Short Circuit Withstand Application Internal Circuit Diagram UPS Systems High Power Converters Solar Applications Motor Drives Traction ...
